372 Spanning-Tree Commands
Console# show spanning-tree
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
Path Cost 20000
Root Port 1 (g1)
Hello Time 2 sec Max Age 20 sec Forward
Delay 15 sec
IST Master ID Priority 32768
Address 00:02:4b:29:7a:00
Hello Time 2 sec. Max Age 20 sec Forward Delay 15 sec Max hops 20
Interfaces
Name State Prio.Nbr Cost Sts Role PortFast Type
1 Enabled 128.1 20000 FWD Root No P2p Bound (RSTP)
2 Enabled 128.2 20000 FWD Desg No Shared Bound (STP)
3 Enabled 128.3 20000 FWD Desg No P2p
4 Enabled 128.4 20000 FWD Desg No P2p
##### MST 1 Vlans Mapped: 10-20
Root ID Priority 24576
Address 00:02:4b:29:89:76
Path Cost 20000
Root Port 4(1/4)
Rem hops 19
5400_CLI.book Page 372 Wednesday, December 17, 2008 4:33 PM
