iView - Controller View
9-144 Manual # 42-02-7223
• Car Calls - Rear Main COP
• Car Call - Rear Main COP light, Floor 1—96: Outputs to the rear main Car Operating
Panel lights.
• Car Calls - Front Aux COP
• Car Call - Front Aux COP light, Floor 1—96: Outputs to the front Aux Car Operating
Panel lights.
• Car Calls - Rear Aux COP
• Car Call - Rear Aux COP light, Floor 1—96: Outputs to the rear Aux Car Operating
Panel lights.
• Position indicators Digital Outputs I
• Digital Position Indicator I, Output 1— 8: Outputs 1 through 8 to Digital Position Indi-
cator I. Outputs I will stay active during Fire Service.
• Position indicators Digital Outputs II
• Digital Position Indicators II, Output 1—8: Outputs 1 through 8 to Digital Position
Indicator II. Outputs II will deactivate during Fire Service.
• Position indicators Single Outputs I
• Position Indicators Single I, Floor 1—64: Outputs to one line per floor position indica-
tors. Outputs I will stay active during Fire Service.
• Position indicators Single Outputs II
• Position Indicators Single II, Floor 1—64: Outputs to one line per floor position indica-
tors. Outputs II will deactivate during Fire Service.
• Position indicators Rotodial Outputs I
• Rotodial Position Indicators I, Output 1—3: Outputs created for the “Rotodial” brand
position indicators. These three outputs change in a specified pattern to cause the
rotodial device to rotate in the appropriate direction. Outputs I will stay active during
Fire Service.
• Position indicators Rotodial Outputs II
• Rotodial Position Indicators II, Output 1—3: Outputs created for the “Rotodial” brand
position indicators. These three outputs change in a specified pattern to cause the
rotodial device to rotate in the appropriate direction. Outputs II will deactivate during
Fire Service.
• Hall lanterns - Front up
• Hall lantern - Front up, Floor 1—96: This output is generated to activate the front door
hall gong/lantern assembly. Options are set on the Configuration > Car Operation >
Devices tab.
• Hall lanterns - Front down
• Hall lantern - Front down, Floor 1—96: This output is generated to activate the front
door hall gong/lantern assembly. Options are set on the Configuration > Car Opera-
tion > Devices tab.
• Hall lanterns - Rear up
• Hall lantern - Rear up, Floor 1—96: This output is generated to activate the rear door
hall gong/lantern assembly. Options are set on the Configuration > Car Operation >
Devices tab.
