Figure 102 Detection cell heater door (visible only when the oven door is open)
Control and connection symbols
Symbols and
descriptions
On (Power)
O (P
ower)
On-O (P
ower)
Earth (ground) terminal
Protective conductor terminal (main ground)
Direct current
Alternating current
Both direct and alternating current
Appendix F Safety
Symbols on this instrument
F
SeqStudio
Flex Series Genetic Analyzer with Instrument Software v1.0 User Guide
