5 Commands by Subsystem
Display Menu
Definite persistence Off
Grid 33%
Vectors On
Quick Meas Menu
Source Channel 1
Run Control
Scope is running
Time Base Menu
Main time/division 100 us
Main time base delay 0.00 s
Delay time/division 500 ns
Delay time base delay 0.00 s
Reference center
Mode main
Vernier Off
Trigger Menu
Ty p e E d g e
Mode Auto
Coupling dc
Source Channel 1
Level 0.0 V
Slope Positive
HF Reject and noise reject Off
Holdoff 60 ns
External probe attenuation AutoProbe (if AutoProbe is connected),
otherwise 1.0:1
