Commands by Subsystem 5

Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 481

:TRIGger:TV:MODE

(see page 658)

Command Syntax

:TRIGger:TV:MODE <mode>

<mode> ::= {FIEld1 | FIEld2 | AFIelds | ALINes | LINE | VERTical

| LFIeld1 | LFIeld2 | LALTernate | LVERtical}

The :TRIGger:TV:MODE command selects the TV trigger mode and field.

The LVERtical parameter is only available when :TRIGger:TV:STANdard is

GENeric. The LALTernate parameter is not available when

:TRIGger:TV:STANdard is GENeric.

Old forms for <mode> are accepted:

Query Syntax

:TRIGger:TV:MODE?

The :TRIGger:TV:MODE? query returns the TV trigger mode.

Return Format

<value> ::= {FIE1 | FIE2 | AFI | ALIN | LINE | VERT | LFI1 | LFI2

| LALT | LVER}

See Also • "Introduction to :TRIGger Commands" on page 411

• ":TRIGger:TV:STANdard" on page 484

• ":TRIGger:MODE" on page 417

<mode> Old Forms Accepted

FIEld1 F1

FIEld2 F2

AFIelds ALLFields, ALLFLDS

ALINes ALLLines

LFIeld1 LINEF1, LINEFIELD1

LFIeld2 LINEF2, LINEFIELD2

LALTernate LINEAlt

LVERtical LINEVert
