440 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide

5 Commands by Subsystem

:TRIGger[:EDGE]:COUPling

(see page 658)

Command Syntax

:TRIGger[:EDGE]:COUPling <coupling>

<coupling> ::= {AC | DC | LFReject}

The :TRIGger[:EDGE]:COUPling command sets the input coupling for the

selected trigger sources. The coupling can be set to AC, DC, or LFReject.

• AC coupling places a high- pass filter (10 Hz for analog channels, and

3.5 Hz for all External trigger inputs) in the trigger path, removing dc

offset voltage from the trigger waveform. Use AC coupling to get a

stable edge trigger when your waveform has a large dc offset.

• LFReject coupling places a 50 KHz high-pass filter in the trigger path.

• DC coupling allows dc and ac signals into the trigger path.

Query Syntax

:TRIGger[:EDGE]:COUPling?

The :TRIGger[:EDGE]:COUPling? query returns the current coupling

selection.

Return Format

<coupling> ::= {AC | DC | LFR}

See Also • "Introduction to :TRIGger Commands" on page 411

• ":TRIGger:MODE" on page 417

• ":TRIGger[:EDGE]:REJect" on page 442

NOTE

The :TRIGger[:EDGE]:COUPling and the :TRIGger[:EDGE]:REJect selections are coupled.

Changing the setting of the :TRIGger[:EDGE]:REJect can change the COUPling setting.
