390 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide

5 Commands by Subsystem

:SBUS:UART:FRAMing

(see page 658)

Command Syntax

:SBUS:UART:FRAMing <value>

<value> ::= {OFF | <decimal> | <nondecimal>}

<decimal> ::= 8-bit integer in decimal from 0-255 (0x00-0xff)

<nondecimal> ::= #Hnn where n ::= {0,..,9 | A,..,F} for hexadecimal

<nondecimal> ::= #Bnn...n where n ::= {0 | 1} for binary

The :SBUS:UART:FRAMing command determines the byte value to use for

framing (end of packet) or to turn off framing for UART decode.

Query Syntax

:SBUS:UART:FRAMing?

The :SBUS:UART:FRAMing? query returns the current UART decode base

setting.

Return Format

<value> ::= {OFF | <decimal>}

<decimal> ::= 8-bit integer in decimal from 0-255

Errors • "- 241, Hardware missing" on page 617

See Also • "Introduction to :SBUS Commands" on page 374

• ":TRIGger:UART Commands" on page 485

NOTE

This command is only valid on 4 (analog) channel oscilloscope models when the

UART/RS-232 triggering and serial decode option (Option 232) has been licensed.
