Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

470 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:TRIGger:SPI Commands
Table 67 :TRIGger:SPI Commands Summary
Command Query Options and Query Returns
:TRIGger:SPI:CLOCk:SL
OPe <slope> (see
page 471)
:TRIGger:SPI:CLOCk:SL
OPe? (see page 471)
<slope> ::= {NEGative | POSitive}
:TRIGger:SPI:CLOCk:TI
Meout <time_value>
(see page 472)
:TRIGger:SPI:CLOCk:TI
Meout? (see page 472)
<time_value> ::= time in seconds
in NR1 format
:TRIGger:SPI:FRAMing
<value> (see
page 473)
:TRIGger:SPI:FRAMing?
(see page 473)
<value> ::= {CHIPselect |
NOTChipselect | TIMeout}
:TRIGger:SPI:PATTern:
DATA <value>, <mask>
(see page 474)
:TRIGger:SPI:PATTern:
DATA? (see page 474)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= "0xnnnnnn" where n
::= {0,..,9 | A,..,F}
:TRIGger:SPI:PATTern:
WIDTh <width> (see
page 475)
:TRIGger:SPI:PATTern:
WIDTh? (see page 475)
<width> ::= integer from 4 to 32
in NR1 format
:TRIGger:SPI:SOURce:C
LOCk <source> (see
page 476)
:TRIGger:SPI:SOURce:C
LOCk? (see page 476)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:D
ATA <source> (see
page 477)
:TRIGger:SPI:SOURce:D
ATA? (see page 477)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:F
RAMe <source> (see
page 478)
:TRIGger:SPI:SOURce:F
RAMe? (see page 478)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
