:TRIGger:LIN Commands
Table 66 :TRIGger:LIN Commands Summary
Command Query Options and Query Returns
:TRIGger:LIN:ID
<value> (see
page 463)
:TRIGger:LIN:ID? (see
page 463)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
(with Option AMS)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:TRIGger:LIN:SAMPlepo
int <value> (see
page 464)
:TRIGger:LIN:SAMPlepo
int? (see page 464)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:TRIGger:LIN:SIGNal:B
AUDrate <baudrate>
(see page 465)
:TRIGger:LIN:SIGNal:B
AUDrate? (see
page 465)
<baudrate> ::= integer from 2400
to 625000 in 100 b/s increments
:TRIGger:LIN:SOURce
<source> (see
page 466)
:TRIGger:LIN:SOURce?
(see page 466)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:LIN:STANdard
<std> (see page 467)
:TRIGger:LIN:STANdard
? (see page 467)
<std> ::= {LIN13 | LIN20}
:TRIGger:LIN:SYNCbrea
k <value> (see
page 468)
:TRIGger:LIN:SYNCbrea
k? (see page 468)
<value> ::= integer = {11 | 12 |
13}
:TRIGger:LIN:TRIGger
<condition> (see
page 469)
:TRIGger:LIN:TRIGger?
(see page 469)
<condition> ::= {SYNCbreak}
(without Option AMS)
<condition> ::= {SYNCbreak | ID}
(with Option AMS)
