612 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide

7 Obsolete and Discontinued Commands

:TRIGger:LIN:SIGNal:DEFinition

(see page 658)

Command Syntax

:TRIGger:LIN:SIGNal:DEFinition <value>

<value> ::= {LIN | RX | TX}

The :TRIGger:LIN:SIGNal:DEFinition command sets the LIN signal type.

These signals can be set to:

Dominant low signals:

• LIN — the actual LIN single- end bus signal line.

• RX — the Receive signal from the LIN bus transceiver.

• TX — the Transmit signal to the LIN bus transceiver.

Query Syntax

:TRIGger:LIN:SIGNal:DEFinition?

The :TRIGger:LIN:SIGNal:DEFinition? query returns the current LIN signal

type.

Return Format

<value> ::= LIN

See Also • "Introduction to :TRIGger Commands" on page 411

• ":TRIGger:MODE" on page 417

• ":TRIGger:LIN:SIGNal:BAUDrate" on page 465

• ":TRIGger:LIN:SOURce" on page 466

NOTE

With InfiniiVision 5000 Series oscilloscope software version 5.00 or greater, this command

is available, but the only legal value is LIN.
