Commands by Subsystem 5

Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 173

:ACQuire:SEGMented:INDex

(see page 658)

Command Syntax

:ACQuire:SEGMented:INDex <index>

<index> ::= an integer from 2 to 250 in NR1 format

The :ACQuire:SEGMented:INDex command sets the index into the memory

segments that have been acquired.

The segmented memory acquisition mode is enabled with the

:ACQuire:MODE command. The number of segments to acquire is set using

the :ACQuire:SEGMented:COUNt command, and data is acquired using the

:DIGitize, :SINGle, or :RUN commands. The number of memory segments

that have been acquired is returned by the :WAVeform:SEGMented:COUNt?

query. The time tag of the currently indexed memory segment is returned

by the :WAVeform:SEGMented:TTAG? query.

Query Syntax

:ACQuire:SEGMented:INDex?

The :ACQuire:SEGMented:INDex? query returns the current segmented

memory index setting.

Return Format

<index> ::= an integer from 2 to 250 in NR1 format

See Also • ":ACQuire:MODE" on page 169

• ":ACQuire:SEGMented:COUNt" on page 172

• ":DIGitize" on page 132

• ":SINGle" on page 158

• ":RUN" on page 156

• ":WAVeform:SEGMented:COUNt" on page 519

• ":WAVeform:SEGMented:TTAG" on page 520

• ":ACQuire:SEGMented:ANALyze" on page 171

• "Introduction to :ACQuire Commands" on page 163

Example Code

' Segmented memory commands example.

' -------------------------------------------------------------------

Option Explicit

Public myMgr As VisaComLib.ResourceManager

Public myScope As VisaComLib.FormattedIO488

NOTE

This command is available when the segmented memory option (Option SGM) is enabled.
