360 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide

5 Commands by Subsystem

:SAVE:IMAGe[:STARt]

(see page 658)

Command Syntax

:SAVE:IMAGe[:STARt] [<file_spec>]

<file_spec> ::= {<internal_loc> | <file_name>}

<internal_loc> ::= 0-9; an integer in NR1 format

<file_name> ::= quoted ASCII string

The :SAVE:IMAGe[:STARt] command saves an image.

See Also • "Introduction to :SAVE Commands" on page 358

• ":SAVE:IMAGe:AREA" on page 361

• ":SAVE:IMAGe:FACTors" on page 362

• ":SAVE:IMAGe:FORMat" on page 363

• ":SAVE:IMAGe:INKSaver" on page 364

• ":SAVE:IMAGe:PALette" on page 365

• ":SAVE:FILename" on page 359

• ":RECall:IMAGe[:STARt]" on page 353

NOTE

If a file extension is provided as part of a specified <file_name>, and it does not match the

extension expected by the format specified in :SAVE:IMAGe:FORMat, the format will be

changed if the extension is a valid image file extension.

NOTE

If the extension ".bmp" is used and the current :SAVE:IMAGe:FORMat is not BMP or BMP8,

the format will be changed to BMP.

NOTE

When the <internal_loc> option is used, the :SAVE:IMAGe:FORMat will be changed to TIFF.
