:SBUS Commands
Control oscilloscope functions associated with the serial decode bus. See
"Introduction to :SBUS Commands" on page 374.
Table 57 :SBUS Commands Summary
Command Query Options and Query Returns
n/a :SBUS:CAN:COUNt:ERRor
? (see page 375)
<frame_count> ::= integer in NR1
format
n/a :SBUS:CAN:COUNt:OVERl
oad? (see page 376)
<frame_count> ::= integer in NR1
format
:SBUS:CAN:COUNt:RESet
(see page 377)
n/a n/a
n/a :SBUS:CAN:COUNt:TOTal
? (see page 378)
<frame_count> ::= integer in NR1
format
n/a :SBUS:CAN:COUNt:UTILi
zation? (see
page 379)
<percent> ::= floating-point in
NR3 format
:SBUS:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 380)
:SBUS:DISPlay? (see
page 380)
{0 | 1}
:SBUS:IIC:ASIZe
<size> (see page 381)
:SBUS:IIC:ASIZe? (see
page 381)
<size> ::= {BIT7 | BIT8}
:SBUS:LIN:PARity {{0
| OFF} | {1 | ON}}
(see page 382)
:SBUS:LIN:PARity?
(see page 382)
{0 | 1}
:SBUS:MODE <mode>
(see page 383)
:SBUS:MODE? (see
page 383)
<mode> ::= {IIC | SPI | CAN | LIN
| FLEXray | UART}
:SBUS:SPI:WIDTh
<word_width> (see
page 384)
:SBUS:SPI:WIDTh? (see
page 384)
<word_width> ::= integer 4-16 in
NR1 format
:SBUS:UART:BASE
<base> (see page 385)
:SBUS:UART:BASE? (see
page 385)
<base> ::= {ASCii | BINary | HEX}
n/a :SBUS:UART:COUNt:ERRo
r? (see page 386)
<frame_count> ::= integer in NR1
format
:SBUS:UART:COUNt:RESe
t (see page 387)
n/a n/a
n/a :SBUS:UART:COUNt:RXFR
ames? (see page 388)
<frame_count> ::= integer in NR1
format
