414 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
General :TRIGger Commands
Table 60 General :TRIGger Commands Summary
Command Query Options and Query Returns
:TRIGger:HFReject {{0
| OFF} | {1 | ON}}
(see page 415)
:TRIGger:HFReject?
(see page 415)
{0 | 1}
:TRIGger:HOLDoff
<holdoff_time> (see
page 416)
:TRIGger:HOLDoff?
(see page 416)
<holdoff_time> ::= 60 ns to 10 s
in NR3 format
:TRIGger:MODE <mode>
(see page 417)
:TRIGger:MODE? (see
page 417)
<mode> ::= {EDGE | GLITch |
PATTern | DURation | TV}
<return_value> ::= {<mode> |
<none>}
<none> ::= query returns "NONE"
if the :TIMebase:MODE is ROLL or
XY
:TRIGger:NREJect {{0
| OFF} | {1 | ON}}
(see page 418)
:TRIGger:NREJect?
(see page 418)
{0 | 1}
:TRIGger:PATTern
<value>, <mask>
[,<edge
source>,<edge>] (see
page 419)
:TRIGger:PATTern?
(see page 419)
<value> ::= integer in NR1 format
or <string>
<mask> ::= integer in NR1 format
or <string>
<string> ::= "0xnn"; n ::=
{0,..,9 | A,..,F} (# bits = #
channels)
<edge source> ::= {CHANnel<n> |
EXTernal | NONE}
<edge> ::= {POSitive | NEGative}
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SWEep
<sweep> (see
page 421)
:TRIGger:SWEep? (see
page 421)
<sweep> ::= {AUTO | NORMal}
