Commands by Subsystem 5
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 487
:TRIGger:UART:BASE
(see page 658)
Command Syntax
:TRIGger:UART:BASE <base>
<base> ::= {ASCii | HEX}
The :TRIGger:UART:BASE command sets the front panel UART/RS232
trigger setup data selection option:
• ASCii — front panel data selection is from ASCII values.
• HEX — front panel data selection is from hexadecimal values.
The :TRIGger:UART:BASE setting does not affect the :TRIGger:UART:DATA
command which can always set data values using ASCII or hexadecimal
values.
Query Syntax
:TRIGger:UART:BASE?
The :TRIGger:UART:BASE? query returns the current UART base setting.
Return Format
<base><NL>
<base> ::= {ASC | HEX}
See Also • "Introduction to :TRIGger Commands" on page 411
• ":TRIGger:MODE" on page 417
• ":TRIGger:UART:DATA" on page 491
NOTE
The :TRIGger:UART:BASE command is independent of the :SBUS:UART:BASE command
which affects decode only.
