:TRIGger:CAN:SIGNal:DEFinition
(see page 658)
Command Syntax
:TRIGger:CAN:SIGNal:DEFinition <value>
<value> ::= {CANH | CANL | RX | TX | DIFFerential}
The :TRIGger:CAN:SIGNal:DEFinition command sets the CAN signal type
when :TRIGger:CAN:TRIGger is set to SOF (start of frame). These signals
can be set to:
Dominant high signal:
• CANH — the actual CAN_H differential bus signal.
Dominant low signals:
• CANL — the actual CAN_L differential bus signal.
• RX — the Receive signal from the CAN bus transceiver.
• TX — the Transmit signal to the CAN bus transceiver.
• DIFFerential — the CAN differential bus signal connected to an analog
source channel using a differential probe.
Query Syntax
:TRIGger:CAN:SIGNal:DEFinition?
The :TRIGger:CAN:SIGNal:DEFinition? query returns the current CAN
signal type.
Return Format
<value><NL>
<value> ::= DIFF
See Also • "Introduction to :TRIGger Commands" on page 411
• ":TRIGger:MODE" on page 417
• ":TRIGger:CAN:SIGNal:BAUDrate" on page 429
• ":TRIGger:CAN:SOURce" on page 430
• ":TRIGger:CAN:TRIGger" on page 431
NOTE
With InfiniiVision 5000 Series oscilloscope software version 5.00 or greater, this command
is available, but the only legal value is DIFF.
