:TRIGger:UART Commands
Table 70 :TRIGger:UART Commands Summary
Command Query Options and Query Returns
:TRIGger:UART:BASE
<base> (see page 487)
:TRIGger:UART:BASE?
(see page 487)
<base> ::= {ASCii | HEX}
:TRIGger:UART:BAUDrat
e <baudrate> (see
page 488)
:TRIGger:UART:BAUDrat
e? (see page 488)
<baudrate> ::= integer from 1200
to 3000000 in 100 b/s increments
:TRIGger:UART:BITorde
r <bitorder> (see
page 489)
:TRIGger:UART:BITorde
r? (see page 489)
<bitorder> ::= {LSBFirst |
MSBFirst}
:TRIGger:UART:BURSt
<value> (see
page 490)
:TRIGger:UART:BURSt?
(see page 490)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
:TRIGger:UART:DATA
<value> (see
page 491)
:TRIGger:UART:DATA?
(see page 491)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9 | A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
:TRIGger:UART:IDLE
<time_value> (see
page 492)
:TRIGger:UART:IDLE?
(see page 492)
<time_value> ::= time from 1 us
to 10 s in NR3 format
:TRIGger:UART:PARity
<parity> (see
page 493)
:TRIGger:UART:PARity?
(see page 493)
<parity> ::= {EVEN | ODD | NONE}
:TRIGger:UART:POLarit
y <polarity> (see
page 494)
:TRIGger:UART:POLarit
y? (see page 494)
<polarity> ::= {HIGH | LOW}
:TRIGger:UART:QUALifi
er <value> (see
page 495)
:TRIGger:UART:QUALifi
er? (see page 495)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
