Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

228 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:FUNCtion Commands
Control functions in the measurement/storage module. See "Introduction to
:FUNCtion Commands" on page 230.
Table 50 :FUNCtion Commands Summary
Command Query Options and Query Returns
:FUNCtion:CENTer
<frequency> (see
page 231)
:FUNCtion:CENTer?
(see page 231)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
0 Hz to 25 GHz.
:FUNCtion:DISPlay {{0
| OFF} | {1 | ON}}
(see page 232)
:FUNCtion:DISPlay?
(see page 232)
{0 | 1}
:FUNCtion:GOFT:OPERat
ion <operation> (see
page 233)
:FUNCtion:GOFT:OPERat
ion? (see page 233)
<operation> ::= {ADD | SUBTract |
MULTiply}
:FUNCtion:GOFT:SOURce
1 <source> (see
page 234)
:FUNCtion:GOFT:SOURce
1? (see page 234)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:GOFT:SOURce
2 <source> (see
page 235)
:FUNCtion:GOFT:SOURce
2? (see page 235)
<source> ::= CHANnel<n>
<n> ::= {{1 | 2} | {3 | 4}} for
4ch models, depending on SOURce1
selection
<n> ::= {1 | 2} for 2ch models
:FUNCtion:OFFSet
<offset> (see
page 236)
:FUNCtion:OFFSet?
(see page 236)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:OPERation
<operation> (see
page 237)
:FUNCtion:OPERation?
(see page 237)
<operation> ::= {ADD | SUBTract |
MULTiply | INTegrate |
DIFFerentiate | FFT | SQRT}
