Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands by Subsystem 5
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 229
:FUNCtion:RANGe
<range> (see
page 238)
:FUNCtion:RANGe? (see
page 238)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFFerentiate
function is 80E-3 to 8.0E12
(depends on current sweep speed).
The range for the FFT function is
8 to 800 dBV.
:FUNCtion:REFerence
<level> (see
page 239)
:FUNCtion:REFerence?
(see page 239)
<level> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:SCALe
<scale
value>[<suffix>] (see
page 240)
:FUNCtion:SCALe? (see
page 240)
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
:FUNCtion:SOURce1
<source> (see
page 241)
:FUNCtion:SOURce1?
(see page 241)
<source> ::= {CHANnel<n> | GOFT}
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
GOFT is only for FFT, INTegrate,
DIFFerentiate, and SQRT
operations.
:FUNCtion:SOURce2
<source> (see
page 242)
:FUNCtion:SOURce2?
(see page 242)
<source> ::= {CHANnel<n> | NONE}
<n> ::= {{1 | 2} | {3 | 4}} for
4ch models, depending on SOURce1
selection
<n> ::= {1 | 2} for 2ch models
:FUNCtion:SPAN <span>
(see page 243)
:FUNCtion:SPAN? (see
page 243)
<span> ::= the current frequency
span in NR3 format.
Legal values are 1 Hz to 100 GHz.
:FUNCtion:WINDow
<window> (see
page 244)
:FUNCtion:WINDow?
(see page 244)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
Table 50 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
