Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands by Subsystem 5
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 425
:TRIGger:CAN:PATTern:DATA:LENGth
(see page 658)
Command Syntax
:TRIGger:CAN:PATTern:DATA:LENGth <length>
<length> ::= integer from 1 to 8 in NR1 format
The :TRIGger:CAN:PATTern:DATA:LENGth command sets the number of
8- bit bytes in the CAN data string. The number of bytes in the string can
be anywhere from 0 bytes to 8 bytes (64 bits). The value for these bytes is
set by the :TRIGger:CAN:PATTern:DATA command.
Query Syntax
:TRIGger:CAN:PATTern:DATA:LENGth?
The :TRIGger:CAN:PATTern:DATA:LENGth? query returns the current CAN
data pattern length setting.
Return Format
<count><NL>
<count> ::= integer from 1 to 8 in NR1 format
Errors • "- 241, Hardware missing" on page 617
See Also • "Introduction to :TRIGger Commands" on page 411
• ":TRIGger:CAN:PATTern:DATA" on page 424
• ":TRIGger:CAN:SOURce" on page 430
NOTE
This command is only valid when the automotive CAN and LIN serial decode option (Option
AMS) has been licensed.
