Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

520 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:WAVeform:SEGMented:TTAG
(see page 658)
Query Syntax
:WAVeform:SEGMented:TTAG?
The :WAVeform:SEGMented:TTAG? query returns the time tag of the
currently selected segmented memory index. The index is selected using
the :ACQuire:SEGMented:INDex command.
Return Format
<time_tag> ::= in NR3 format
See Also • ":ACQuire:SEGMented:INDex" on page 173
• "Introduction to :WAVeform Commands" on page 502
Example Code • "Example Code" on page 173
NOTE
This command is available when the segmented memory option (Option SGM) is enabled.
