:TRIGger:IIC Commands
Table 65 :TRIGger:IIC Commands Summary
Command Query Options and Query Returns
:TRIGger:IIC:PATTern:
ADDRess <value> (see
page 454)
:TRIGger:IIC:PATTern:
ADDRess? (see
page 454)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC:PATTern:
DATA <value> (see
page 455)
:TRIGger:IIC:PATTern:
DATA? (see page 455)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC:PATTern:
DATa2 <value> (see
page 456)
:TRIGger:IIC:PATTern:
DATa2? (see page 456)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC[:SOURce]
:CLOCk <source> (see
page 457)
:TRIGger:IIC[:SOURce]
:CLOCk? (see
page 457)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC[:SOURce]
:DATA <source> (see
page 458)
:TRIGger:IIC[:SOURce]
:DATA? (see page 458)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC:TRIGger:
QUALifier <value>
(see page 459)
:TRIGger:IIC:TRIGger:
QUALifier? (see
page 459)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:TRIGger:IIC:TRIGger[
:TYPE] <type> (see
page 460)
:TRIGger:IIC:TRIGger[
:TYPE]? (see
page 460)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACknowledge |
R7Data2 | W7Data2 | RESTart}
