:CHANnel<n> Commands
Control all oscilloscope functions associated with individual analog
channels or groups of channels. See "Introduction to :CHANnel<n>
Commands" on page 190.
Table 47 :CHANnel<n> Commands Summary
Command Query Options and Query Returns
:CHANnel<n>:BWLimit
{{0 | OFF} | {1 |
ON}} (see page 192)
:CHANnel<n>:BWLimit?
(see page 192)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:COUPling
<coupling> (see
page 193)
:CHANnel<n>:COUPling?
(see page 193)
<coupling> ::= {AC | DC}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 194)
:CHANnel<n>:DISPlay?
(see page 194)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:IMPedance
<impedance> (see
page 195)
:CHANnel<n>:IMPedance
? (see page 195)
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:INVert
{{0 | OFF} | {1 |
ON}} (see page 196)
:CHANnel<n>:INVert?
(see page 196)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:LABel
<string> (see
page 197)
:CHANnel<n>:LABel?
(see page 197)
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:OFFSet
<offset>[suffix] (see
page 198)
:CHANnel<n>:OFFSet?
(see page 198)
<offset> ::= Vertical offset
value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4; in NR1 format
:CHANnel<n>:PROBe
<attenuation> (see
page 199)
:CHANnel<n>:PROBe?
(see page 199)
<attenuation> ::= Probe
attenuation ratio in NR3 format
<n> ::= 1-2 or 1-4r in NR1 format
n/a :CHANnel<n>:PROBe:ID?
(see page 200)
<probe id> ::= unquoted ASCII
string up to 11 characters
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 201)
:CHANnel<n>:PROBe:SKE
W? (see page 201)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1-2 or 1-4 in NR1 format
