5 Commands by Subsystem
Introduction to
:CHANnel<n>
Commands
<n>::={1|2|3|4}forthefour channel oscilloscope models
<n> ::= {1 | 2} for the two channel oscilloscope models
The CHANnel<n> subsystem commands control an analog channel (vertical
or Y- axis of the oscilloscope). Channels are independently programmable
for all offset, probe, coupling, bandwidth limit, inversion, vernier, and
range (scale) functions. The channel number (1, 2, 3, or 4) specified in the
command selects the analog channel that is affected by the command.
A label command provides identifying annotations of up to 10 characters.
You can toggle the channel displays on and off with the
:CHANnel<n>:DISPlay command as well as with the root level commands
:VIEW and :BLANk.
Reporting the Setup
Use :CHANnel1?, :CHANnel2?, :CHANnel3? or :CHANnel4? to query setup
information for the CHANnel<n> subsystem.
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 202)
:CHANnel<n>:PROBe:STY
Pe? (see page 202)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROTectio
n (see page 203)
:CHANnel<n>:PROTectio
n? (see page 203)
{NORM | TRIP}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 204)
:CHANnel<n>:RANGe?
(see page 204)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 205)
:CHANnel<n>:SCALe?
(see page 205)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:UNITs
<units> (see
page 206)
:CHANnel<n>:UNITs?
(see page 206)
<units> ::= {VOLT | AMPere}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 207)
:CHANnel<n>:VERNier?
(see page 207)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
Table 47 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
NOTE
The obsolete CHANnel subsystem is supported.
