Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands by Subsystem 5
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 427
:TRIGger:CAN:PATTern:ID:MODE
(see page 658)
Command Syntax
:TRIGger:CAN:PATTern:ID:MODE <value>
<value> ::= {STANdard | EXTended}
The :TRIGger:CAN:PATTern:ID:MODE command sets the CAN identifier
mode. STANdard selects the standard 11-bit identifier. EXTended selects
the extended 29- bit identifier. The CAN identifier is set by the
:TRIGger:CAN:PATTern:ID command.
Query Syntax
:TRIGger:CAN:PATTern:ID:MODE?
The :TRIGger:CAN:PATTern:ID:MODE? query returns the current setting of
the CAN identifier mode.
Return Format
<value><NL>
<value> ::= {STAN | EXT}
Errors • "- 241, Hardware missing" on page 617
See Also • "Introduction to :TRIGger Commands" on page 411
• ":TRIGger:MODE" on page 417
• ":TRIGger:CAN:PATTern:DATA" on page 424
• ":TRIGger:CAN:PATTern:DATA:LENGth" on page 425
• ":TRIGger:CAN:PATTern:ID" on page 426
NOTE
This command is only valid when the automotive CAN and LIN serial decode option (Option
AMS) has been licensed.
