374 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide

5 Commands by Subsystem

Introduction to

:SBUS

Commands

The :SBUS subsystem commands control the serial decode bus viewing,

mode, and other options.

Reporting the Setup

Use :SBUS? to query setup information for the :SBUS subsystem.

Return Format

The following is a sample response from the :SBUS? query. In this case,

the query was issued following a *RST command.

:SBUS:DISP 0;MODE IIC

n/a :SBUS:UART:COUNt:TXFR

ames? (see page 389)

<frame_count> ::= integer in NR1

format

:SBUS:UART:FRAMing

<value> (see

page 390)

:SBUS:UART:FRAMing?

(see page 390)

<value> ::= {OFF | <decimal> |

<nondecimal>}

<decimal> ::= 8-bit integer from

0-255 (0x00-0xff)

<nondecimal> ::= #Hnn where n ::=

{0,..,9 | A,..,F} for hexadecimal

<nondecimal> ::= #Bnn...n where n

::= {0 | 1} for binary

Table 57 :SBUS Commands Summary (continued)

Command Query Options and Query Returns

NOTE

These commands are only valid on 4 (analog) channel oscilloscope models when a serial

decode option has been licensed.

Agilent Technologies InfiniiVision 5000 Series Programmer's Guide
