5 Commands by Subsystem
Return Format <value><NL>
<value> ::= integer in NR1 format.
See Also • "Introduction to Root (:) Commands" on page 124
• ":CHANnel<n>:PROTection" on page 203
• ":EXTernal:PROTection" on page 225
• ":OPEE (Operation Status Enable Register)" on page 145
• ":OVLenable (Overload Event Enable Register)" on page 151
• "*STB (Read Status Byte)" on page 117
• "*SRE (Service Request Enable)" on page 115
4 External Trigger OVL Overload has occurred on External Trigger input.
3 Channel 4 OVL Overload has occurred on Channel 4 input.
2 Channel 3 OVL Overload has occurred on Channel 3 input.
1 Channel 2 OVL Overload has occurred on Channel 2 input.
0 Channel 1 OVL Overload has occurred on Channel 1 input.
Table 44 Overload Event Register (OVLR) (continued)
Bit Description When Set (1 = High = True), Indicates:
