Agilent Technologies InfiniiVision 5000 Series

24 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
Obsolete
Commands
Command Differences
:ACQuire:COUNt (see page 167) The :ACQuire:COUNt 1 command has been
deprecated. The AVERage acquisition type with
a count of 1 is functionally equivalent to the
HRESolution acquisition type; however, you
should select the high-resolution acquisition
mode with the :ACQuire:TYPE HRESolution
command instead.
:FUNCtion:OPERation (see page 237) The ADD parameter is new, and now that
waveform math can be performed using
channels 3 and 4, this command selects the
operation only.
:FUNCtion:WINDow (see page 244) You can now select the Blackman-Harris FFT
window.
Obsolete Command Current Command Equivalent Behavior Differences
:FUNCtion:SOURce (see
page 576)
:FUNCtion:SOURce1 (see
page 241)
Obsolete command has ADD,
SUBTract, and MULTiply
parameters; current command
has GOFT parameter.
