Commands by Subsystem 5

Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 257

Introduction to

:MARKer

Commands

The MARKer subsystem commands set and query the settings of X-axis

markers (X1 and X2 cursors) and the Y- axis markers (Y1 and Y2 cursors).

You can set and query the marker mode and source, the position of the X

and Y cursors, and query delta X and delta Y cursor values.

Reporting the Setup

Use :MARKer? to query setup information for the MARKer subsystem.

Return Format

The following is a sample response from the :MARKer? query. In this case,

the query was issued following a *RST and :MARKer:MODE:MANual

command.

:MARK:X1Y1 NONE;X2Y2 NONE;MODE OFF

:MARKer:Y2Position

<position>[suffix]

(see page 265)

:MARKer:Y2Position?

(see page 265)

<position> ::= Y2 cursor position

value in NR3 format

[suffix] ::= {V | mV | dB}

<return_value> ::= Y2 cursor

position value in NR3 format

n/a :MARKer:YDELta? (see

page 266)

<return_value> ::= Y cursors

delta value in NR3 format

Table 52 :MARKer Commands Summary (continued)

Command Query Options and Query Returns
