4 Commands Quick Reference
Table 11 :MARKer Commands Summary
Command Query Options and Query Returns
:MARKer:MODE <mode>
(see page 258)
:MARKer:MODE? (see
page 258)
<mode> ::= {OFF | MEASurement |
MANual | WAVeform}
:MARKer:X1Position
<position>[suffix]
(see page 259)
:MARKer:X1Position?
(see page 259)
<position> ::= X1 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X1 cursor
position value in NR3 format
:MARKer:X1Y1source
<source> (see
page 260)
:MARKer:X1Y1source?
(see page 260)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= <source>
:MARKer:X2Position
<position>[suffix]
(see page 261)
:MARKer:X2Position?
(see page 261)
<position> ::= X2 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X2 cursor
position value in NR3 format
:MARKer:X2Y2source
<source> (see
page 262)
:MARKer:X2Y2source?
(see page 262)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= <source>
n/a :MARKer:XDELta? (see
page 263)
<return_value> ::= X cursors
delta value in NR3 format
:MARKer:Y1Position
<position>[suffix]
(see page 264)
:MARKer:Y1Position?
(see page 264)
<position> ::= Y1 cursor position
value in NR3 format
[suffix] ::= {V | mV | dB}
<return_value> ::= Y1 cursor
position value in NR3 format
:MARKer:Y2Position
<position>[suffix]
(see page 265)
:MARKer:Y2Position?
(see page 265)
<position> ::= Y2 cursor position
value in NR3 format
[suffix] ::= {V | mV | dB}
<return_value> ::= Y2 cursor
position value in NR3 format
n/a :MARKer:YDELta? (see
page 266)
<return_value> ::= Y cursors
delta value in NR3 format
