Page #83 background image
Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 83
:TRIGger:CAN:SOURce
<source> (see
page 430)
:TRIGger:CAN:SOURce?
(see page 430)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 |} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:CAN:TRIGger
<condition> (see
page 431)
:TRIGger:CAN:TRIGger?
(see page 432)
<condition> ::= {SOF} (without
Option AMS)
<condition> ::= {SOF | DATA |
ERRor | IDData | IDEither |
IDRemote | ALLerrors | OVERload |
ACKerror} (with Option AMS)
Table 20 :TRIGger:CAN Commands Summary (continued)
Command Query Options and Query Returns
Table 21 :TRIGger:DURation Commands Summary
Command Query Options and Query Returns
:TRIGger:DURation:GRE
aterthan <greater
than time>[suffix]
(see page 434)
:TRIGger:DURation:GRE
aterthan? (see
page 434)
<greater_than_time> ::=
floating-point number in NR3
format
[suffix] ::= {s | ms | us | ns |
ps}
:TRIGger:DURation:LES
Sthan <less than
time>[suffix] (see
page 435)
:TRIGger:DURation:LES
Sthan? (see page 435)
<less_than_time> ::=
floating-point number from in NR3
format
[suffix] ::= {s | ms | us | ns |
ps}
:TRIGger:DURation:PAT
Tern <value>, <mask>
(see page 436)
:TRIGger:DURation:PAT
Tern? (see page 436)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= ""0xnnnnnn"" n ::=
{0,..,9 | A,..,F}
:TRIGger:DURation:QUA
Lifier <qualifier>
(see page 437)
:TRIGger:DURation:QUA
Lifier? (see
page 437)
<qualifier> ::= {GREaterthan |
LESSthan | INRange | OUTRange |
TIMeout}
:TRIGger:DURation:RAN
Ge
<less_than_time>[suff
ix],
<greater_than_time>[s
uffix] (see page 438)
:TRIGger:DURation:RAN
Ge? (see page 438)
<less_than_time> ::= 15 ns to
10 seconds in NR3 format
<greater_than_time> ::= 10 ns to
9.99 seconds in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
