Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 89
:TRIGger:UART:SOURce:
TX <source> (see
page 497)
:TRIGger:UART:SOURce:
TX? (see page 497)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:UART:TYPE
<value> (see
page 498)
:TRIGger:UART:TYPE?
(see page 498)
<value> ::= {RSTArt | RSTOp |
RDATa | RD1 | RD0 | RDX |
PARityerror | TSTArt | TSTOp |
TDATa | TD1 | TD0 | TDX}
:TRIGger:UART:WIDTh
<width> (see
page 499)
:TRIGger:UART:WIDTh?
(see page 499)
<width> ::= {5 | 6 | 7 | 8 | 9}
Table 27 :TRIGger:UART Commands Summary (continued)
Command Query Options and Query Returns
Table 28 :WAVeform Commands Summary
Command Query Options and Query Returns
:WAVeform:BYTeorder
<value> (see
page 507)
:WAVeform:BYTeorder?
(see page 507)
<value> ::= {LSBFirst | MSBFirst}
n/a :WAVeform:COUNt? (see
page 508)
<count> ::= an integer from 1 to
65536 in NR1 format
n/a :WAVeform:DATA? (see
page 509)
<binary block length bytes>,
<binary data>
For example, to transmit 1000
bytes of data, the syntax would
be: #800001000<1000 bytes of
data><NL>
8 is the number of digits that
follow
00001000 is the number of bytes
to be transmitted
<1000 bytes of data> is the
actual data
:WAVeform:FORMat
<value> (see
page 511)
:WAVeform:FORMat?
(see page 511)
<value> ::= {WORD | BYTE | ASCII}
