Power Management

Non-Confidential

Unrestricted Access

Note

If the debug logic is included in a powered-down domain, then nTDOEN needs to be

handled carefully. It cannot be clamped to 0 because this enables it during power down.

Either:

• Insert inverters either side of the clamp.

• Ensure that the external system masks nTDOEN when the core is powered down.

•Clamp nTDOEN to 1 during power down.
