ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 8-21
Unrestricted Access Non-Confidential
Vector Table Offset Register
Use the Vector Table Offset Register to determine:
• if the vector table is in RAM or code memory
• the vector table offset.
The register address, access type, and Reset state are:
Address
0xE000ED08
Access Read/write
Reset state
0x00000000
Figure 8-10 on page 8-22 shows the bit assignments of the Vector Table Offset Register.
[24] - - Reserved
[23] ISRPREEMPT Read-only You must only use this at debug time. It indicates that a pending interrupt
becomes active in the next running cycle. If C_MASKINTS is clear in the
Debug Halting Control and Status Register, the interrupt is serviced.
[22] ISRPENDING Read-only Interrupt pending flag. Excludes NMI and Faults:
1 = interrupt pending
0 = interrupt not pending.
[21:12] VECTPENDING Read-only Pending ISR number field. VECTPENDING contains the interrupt number
of the highest priority pending ISR.
[11] RETTOBASE Read-only This bit is 1 when the set of all active exceptions minus the
IPSR_current_exception yields the empty set.
[10] - - Reserved.
[9] - - Reserved
[8:0] VECTACTIVE Read-only Active ISR number field. VECTACTIVE contains the interrupt number of
the currently running ISR, including NMI and Hard Fault. A shared handler
can use VECTACTIVE to determine which interrupt invoked it. You can
subtract 16 from the VECTACTIVE field to index into the Interrupt
Clear/Set Enable, Interrupt Clear Pending/SetPending and Interrupt Priority
Registers. INTISR[0] has vector number 16.
Reset clears the VECTACTIVE field.
Table 8-15 Interrupt Control State Register bit assignments (continued)
Bits Field Type Function

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
