ARM Cortex-M3 User Manual

ii Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Unrestricted Access
Cortex-M3
Technical Reference Manual
Copyright © 2005-2008 ARM Limited. All rights reserved.
Release Information
The following changes have been made to this book.
Proprietary Notice
Words and logos marked with
®
or
™
are registered trademarks or trademarks of ARM Limited in the EU and
other countries, except as otherwise stated in this proprietary notice. Other brands and names mentioned
herein may be the trademarks of their respective owners.
Neither the whole nor any part of the information contained in, or the product described in, this document
may be adapted or reproduced in any material form except with the prior written permission of the copyright
holder.
The product described in this document is subject to continuous developments and improvements. All
particulars of the product and its use contained in this document are given by ARM Limited in good faith.
However, all warranties implied or expressed, including but not limited to implied warranties of
merchantability, or fitness for purpose, are excluded.
This document is intended only to assist the reader in the use of the product. ARM Limited shall not be liable
for any loss or damage arising from the use of any information in this document, or any error or omission in
such information, or any incorrect use of the product.
Where the term ARM is used it means “ARM or any of its subsidiaries as appropriate”.
Confidentiality Status
This document is Non-Confidential. The right to use, copy and disclose this document may be subject to
license restrictions in accordance with the terms of the agreement entered into by ARM and the party that
ARM delivered this document to.
Unrestricted Access is an ARM internal classification.
Change History
Date Issue Confidentiality Change
15 December 2005 A Confidential First Release
13 January 2006 B Non-Confidential Confidentiality status amended
10 May 2006 C Non-Confidential First Release for r1p0
27 September 2006 D Non-Confidential First Release for r1p1
13 June 2007 E Non-Confidential Minor update with no technical changes
11 April 2008 F Confidential Limited release for SC300 r0p0
26 June 2008 G Non-Confidential First Release for r2p0

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
