Signal Descriptions

Unrestricted Access Non-Confidential

ETMFOLD Output Opcode fold. An IT opcode has been folded in this cycle. PC advances past the

current (16-bit) opcode plus the IT instruction (16 bits). This is reflected in the

ETMIA.

ETMFIFOFULL Input Driven by the ETM (if connected). ETMFIFOFULL is asserted when the

ETM FIFO is full, and causes the processor to stall until the FIFO has drained,

so ensuring that no trace is lost.

DSYNC Output Synchronization pulse from DWT.
