Dell PowerVault ML6000 Maintenance Guide

108 Library Installation and CRU Replacement
7 Remove the power supply by gripping the power supply handle and pulling it toward you.
8 Insert the new power supply into the vacant power supply slot.
When inserting the power supply, make sure that you insert it correctly, with its on/off switch located at
the bottom of the supply, below the handle. The power supply must be level to slide in smoothly.
9 Tighten the power supply’s thumbscrews to secure the power supply to the library module.
10 Reconnect the power supply’s power cord.
11 Turn on the power supply’s power.
12 Check the status of the power supply’s LEDs. The top green LED and the blue LED should be solidly lit.
13 Power on the library.
14 Check the status of the power supply’s LEDs. The two green LEDs should be solidly lit, and the blue
LED should be off.
Using the Rack-mount Kit to Install a Library in a Rack
The rack-mount kit secures your library within a rack. These instructions explain how to install your stand-
alone library into a rack and how to install additional modules into an existing rack.
All libraries taller than 14U must be installed in a rack.The rack secures the bottom module, and all other
modules are then secured to the bottom module.
Installing the modules into the rack requires at least two people.
WARNING
ALL LIBRARIES TALLER THAN 14U MUST BE INSTALLED IN A RACK
HAVING A MAIN PROTECTIVE EARTHING (GROUNDING) TERMINAL,
AND POWER MUST BE SUPPLIED VIA AN INDUSTRIAL PLUG AND
SOCKET-OUTLET AND/OR AN APPLIANCE COUPLER COMPLYING
WITH IEC 60309 (OR AN EQUIVALENT NATIONAL STANDARD) AND
HAVING A PROTECTIVE EARTH (GROUND) CONDUCTOR WITH A
CROSS SECTIONAL AREA OF AT LEAST 1.5 MM
2
(14 AWG).
TO ENSURE PROPER AIRFLOW AND ACCESS SPACE, ALLOW 60 CM
(24 INCHES) IN THE FRONT AND BACK OF THE LIBRARY.
WARNING
UNDER NO CIRCUMSTANCES SHOULD A RACK BE MOVED WHILE
LOADED WITH ONE OR MORE MODULES.
WARNING
WITHOUT TAPE DRIVES, TAPE CARTRIDGES, OR POWER
SUPPLIES, A 5U LIBRARY CONTROL MODULE WEIGHS
APPROXIMATELY 60 LBS (27.2 KG). A 9U EXPANSION MODULE,
WITHOUT TAPE DRIVES, TAPE CARTRIDGES, OR POWER
SUPPLIES, EXCEEDS 65 LBS (29.5 KG).
TO AVOID SERIOUS INJURY, AT LEAST TWO PEOPLE ARE
REQUIRED TO SAFELY LIFT THE MODULES INTO POSITION.
