PowerVault ML6000 Maintenance Guide 79
10 Remove and replace the cover plates, if appropriate.
If you plan to stack the 5U Library Control Module at the top of the library, and if a 9U Expansion
Module will be located below it, remove the 5U Library Control Module’s bottom cover plate and the
9U Expansion Module top plate.
If you plan to stack the 5U Library Control Module between 9U Expansion Modules, remove both
the top and bottom plates of the 5U Library Control Module. Also remove the top plate of the 9U
Expansion Module located below the 5U Library Control Module and the bottom plate of the 9U
Expansion Module located above the 5U Library Control Module.
If you plan to stack the 5U Library Control Module at the bottom of the library, and if a 9U Expansion
Module will be located above it, remove the 5U Library Control Module’s top plate and the 9U
Expansion Module’s bottom plate.
CAUTION
Before removing the 5U Library Control Module’s bottom cover plate,
the robot assembly must be parked as described in P
reparing to
Remove or Replace a Module on page 70.
Table 6 Cover Plate Location after Removing a 9U Expansion Module
5U 14U 23U 32U
cover plate
cover plate 5U Library
Control Module
cover plate 5U Library
Control Module
9U Expansion
Module
cover plate 5U Library
Control Module
9U Expansion
Module
9U Expansion
Module
5U Library
Control Module
9U Expansion
Module
9U Expansion
Module
9U Expansion
Module
cover plate cover plate cover plate cover plate
