78 Library Installation and CRU Replacement
5 Loosen the thumbscrews located at the base of the front of the module.
6 Loosen the two thumbscrews located at the base of the back of the module.
7 Open the module’s access door and raise the guide pin by pulling it up and turning it slightly, as if it were
a screw. Otherwise, the guide pin may scratch the front doors of the module beneath it.
8 From the front of the library, slide the entire module toward you and lift it off of the module below it.
9 Repeat these procedures for each module that you intend to remove.
1 Thumbscrews (behind doors)
