PowerVault ML6000 Maintenance Guide 429
Table 11 Blade Status LEDs.
LED Color Represents Blade Status
Green Library
application
code/Blade
processor
status
• Blinks once per second — Normal operation.
• Solid ON — Not operational.
• Solid OFF — Not operational (or blade is booting).
• Solid ON for 3 seconds, then blinks twice (FC I/O blade only) — Blade
firmware is downloading.
• Blinks 10 times per second (FC I/O blade only) — Identify mode.
Amber Health status • Solid OFF — Normal operation.
• Blinks once per second (LCB only) — Library application code is not
operating, or firmware upgrade/downgrade is in progress on existing
compact flash.
• Solid ON —
• LCB — Failure, or blade is booting up, or initial firmware update on
new compact flash. If solid ON for more than 10 minutes, the LCB
may need to be replaced.
• FC I/O Blade — Failure, or blade is booting up, or blade firmware is
autoleveling.
• FC I/O Fan Blade — There may be one or more problems, including:
fan speed is too high or too low; temperature is too high; there is a
faulty fan speed sensor; or there is a power control problem.
Note: In most cases, solid ON means a failure; however, in
conjunction with the blue LED blinking once every 10 seconds, an
amber LED solid ON can be a normal condition for a short period of
time. Autoleveling takes about three minutes per blade, and blades
autolevel in series.
Never remove a blade when the amber LED is solid ON, unless it
has been on continuously for at least 10 minutes.
Never remove an LCB while the library is powered on.
Blue Power
control status
• Blinks once every 10 seconds — Normal. Blade is powered on.
• Solid ON —
• LCB — Error condition. Power off library before removing or
replacing the LCB.
• FC I/O blade — Swap modeBlade is ready to be removed or
replaced.
• Solid OFF — Blade is not receiving power.
• Blinks once per second (Ethernet Expansion blade) — Powered off.
Ready to remove.
