PowerVault ML6000 Maintenance Guide 431
Figure 29 Location of Tape Drive LEDs
Use Table 14
to interpret tape drive activity:
1 FC port link LED 2 Tape drive LEDs
Table 14 Tape Drive LEDs
LED Color Represents Tape Drive Status
Green Processor activity • Blinks once per second — Normal operation.
• Solid ON/ Solid OFF — Tape drive’s main processor is not
operating.
• 10 blinks per second — Identify mode.
• Blinks 3 times in 3 seconds, then pauses (solid off), and then
repeats — Tape drive is initializing.
• Solid on for 3 seconds, then blinks twice — Tape drive firmware
is downloading.
• 2 quick blinks within 1.25 seconds; then on solid for 1.25
seconds; repeat — Drive sled firmware is downloading.
Amber Health of the drive • Solid OFF — Normal operation.
• Solid ON — Drive has failed.
Blue Power control • Blinks once every 10 seconds — Normal operation.
• Solid ON — Offline. Ready to be removed or replaced.
• Solid OFF — Tape drive is not receiving power.
