442 Library Drawings
Figure 39 Operator Panel
Robot Assembly
As of November 2008, the robot assembly changed. The two robots are identified as follows:
• Pre-November 2008 - Model 1 robot.
• November 2008 and after - Model 2 robot. This robot has an "M2" label on one end to identify it.
Also, the robot controller board is visible on top of the Y-carriage assembly.
Both robot assemblies are shown below. Note that the actual cable spool may look slightly different from
the one shown in Figure 40
.
