36 Library Installation and CRU Replacement
Figure 11 FC With I/O Blade Cabling
1 Library control blade (LCB)
2 GB Ethernet port
3 Power supplies
4 Power cords
5 Ethernet cables from LCB to
expansion module (one per FC I/O
blade)
6 FC cable to tape drive
7 Module terminator
8 FC cable to host
9 Module-to-module cable
10 Ethernet cable to customer
network
11 UPPPER and LOWER Ethernet
ports
4
5
1
4
6
8
7
9
10
2
3
7
11
