Dell PowerVault ML6000 - Figure 22 Bottom Door

160 General Service and Replacing FRUs
5 Gently set the top door down inside the library, taking care not to damage the plastic link that connects
the two doors.
6 On the bottom door, unhook the front spring wire from the tab (see Figure 22
).
7 Unhook the rear spring wire from the notch in the frame (see Figure 22
).
Figure 22 Bottom Door
Left pivot
pin
Press here
Front spring
wire in tab
Rear spring
wire in notch
