PowerVault ML6000 Maintenance Guide 159
3 On the top door, remove the right pivot pin from the right pivot hole by pushing the tab to the left. (The
tab is located on the upper right of the safety door.)
4 On the top door, remove the left pivot pin from the left pivot hole by pushing the flexible piece of the
safety door just beneath the left pivot pin toward the right.
If the top door has a spring, remove it as described in steps Step 6 and
Step 7
on page 160. On very old libraries, there may not be a notch for the
rear spring wire like the one shown in Figure 22
on page 160, but there
may be a small hole in the horizontal metal frame which holds the wire.
Remove the wire from the hole and make sure, when reinstalling, to push
the wire back into the hole.
Right pivot hole
Right pivot pin
Tab
