30 Library Installation and CRU Replacement
4 If the library consists of more than one module, connect the modules together as follows:
a. Using the module terminators, terminate the top and bottom modules in the library stack. Install
one module terminator in the top terminator connector on the topmost module and one in the
bottom terminator connector on the bottommost module.
b. If you need to add 9U Expansion Modules to the 5U Library Control Module, remove the module
terminator from the 5U Library Control Module terminator connection that is closest to the 9U
Expansion Module.
c. Replace the module terminator in the 9U Expansion Module in the terminator connection that
is furthest from the 5U Library Control Module.
d. Connect the module-to-module cable from the 5U Library Control Module to the 9U Expansion
Module.
5 Connect your Ethernet cable to the Gigabit (GB) Ethernet port on the library control blade (LCB) for
remote access to the library via the Web client.
6 Connect a power cord to the outlet on the power supply on the rear of the library.
There should always be a power cord connected to the power supply on the 5U Library Control Module.
If redundant power supplies are used, connect a power cord to each of the additional power supply
outlets.
7 Plug the power cord into a nearby AC power source.
8 Power on the library.
a. Turn on the rear power switch of each of the power supplies.
b. Turn on the front power switch.
c. Power up the host system.
9 Verify communication with all devices on the bus.
10 Configure the library using the commands on the operator panel.
The module terminator is not the same as a SCSI terminator. Using a
SCSI terminator instead of a module terminator will damage the
library.
