Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands by Subsystem 5
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 123
:OPEE <n> (see
page 145)
:OPEE? (see page 146) <n> ::= 16-bit integer in NR1
format
n/a :OPERregister:CONDiti
on? (see page 147)
<n> ::= 16-bit integer in NR1
format
n/a :OPERegister[:EVENt]?
(see page 149)
<n> ::= 16-bit integer in NR1
format
:OVLenable <mask>
(see page 151)
:OVLenable? (see
page 152)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
n/a :OVLRegister? (see
page 153)
<value> ::= integer in NR1
format. See OVLenable for <value>
:PRINt [<options>]
(see page 155)
n/a <options> ::= [<print
option>][,..,<print option>]
<print option> ::= {COLor |
GRAYscale | PRINter0 | BMP8bit |
BMP | PNG | NOFactors | FACTors}
<print option> can be repeated up
to 5 times.
:RUN (see page 156) n/a n/a
n/a :SERial (see
page 157)
<return value> ::= unquoted
string containing serial number
:SINGle (see
page 158)
n/a n/a
n/a :STATus? <display>
(see page 159)
{0 | 1}
<display> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
:STOP (see page 160) n/a n/a
Table 34 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
