58 Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a *STB? (see page 117) <value> ::= 0 to 255; an integer
in NR1 format, as shown in the
following:
Bit Weight Name "1" Indicates
--- ------ ---- ---------------
7 128 OPER Operation status
condition occurred.
6 64 RQS/ Instrument is
MSS requesting service.
5 32 ESB Enabled event status
condition occurred.
4 16 MAV Message available.
3 8 ---- (Not used.)
2 4 MSG Message displayed.
1 2 USR User event
condition occurred.
0 1 TRG A trigger occurred.
*TRG (see page 119) n/a n/a
n/a *TST? (see page 120) <result> ::= 0 or non-zero value;
an integer in NR1 format
*WAI (see page 121) n/a n/a
Table 2 Common (*) Commands Summary (continued)
Command Query Options and Query Returns
Table 3 Root (:) Commands Summary
Command Query Options and Query Returns
n/a :AER? (see page 125) {0 | 1}; an integer in NR1 format
:AUToscale
[<source>[,..,<source
>]] (see page 126)
n/a <source> ::= CHANnel<n>
<source> can be repeated up to 5
times
<n> ::= 1-2 or 1-4 in NR1 format
:AUToscale:AMODE
<value> (see
page 128)
:AUToscale:AMODE?
(see page 128)
<value> ::= {NORMal | CURRent}}
:AUToscale:CHANnels
<value> (see
page 129)
:AUToscale:CHANnels?
(see page 129)
<value> ::= {ALL | DISPlayed}}
:BLANk [<source>]
(see page 130)
n/a <source> ::= {CHANnel<n>} |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
:CDISplay (see
page 131)
n/a n/a
