Agilent Technologies InfiniiVision 5000 Series Programmer's Guide

Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 59
:DIGitize
[<source>[,..,<source
>]] (see page 132)
n/a <source> ::= {CHANnel<n> |
FUNCtion | MATH}
<source> can be repeated up to 5
times
<n> ::= 1-2 or 1-4 in NR1 format
:HWEenable <n> (see
page 134)
:HWEenable? (see
page 134)
<n> ::= 16-bit integer in NR1
format
n/a :HWERregister:CONDiti
on? (see page 136)
<n> ::= 16-bit integer in NR1
format
n/a :HWERegister[:EVENt]?
(see page 138)
<n> ::= 16-bit integer in NR1
format
:MERGe <pixel memory>
(see page 140)
n/a <pixel memory> ::= {PMEMory{0 | 1
| 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9}}
:MTEenable <n> (see
page 141)
:MTEenable? (see
page 141)
<n> ::= 16-bit integer in NR1
format
n/a :MTERegister[:EVENt]?
(see page 143)
<n> ::= 16-bit integer in NR1
format
:OPEE <n> (see
page 145)
:OPEE? (see page 146) <n> ::= 16-bit integer in NR1
format
n/a :OPERregister:CONDiti
on? (see page 147)
<n> ::= 16-bit integer in NR1
format
n/a :OPERegister[:EVENt]?
(see page 149)
<n> ::= 16-bit integer in NR1
format
:OVLenable <mask>
(see page 151)
:OVLenable? (see
page 152)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
n/a :OVLRegister? (see
page 153)
<value> ::= integer in NR1
format. See OVLenable for <value>
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
