Agilent Technologies InfiniiVision 5000 Series

Commands Quick Reference 4
Agilent InfiniiVision 5000 Series Oscilloscopes Programmer's Guide 63
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 201)
:CHANnel<n>:PROBe:SKE
W? (see page 201)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 202)
:CHANnel<n>:PROBe:STY
Pe? (see page 202)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROTectio
n (see page 203)
:CHANnel<n>:PROTectio
n? (see page 203)
{NORM | TRIP}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 204)
:CHANnel<n>:RANGe?
(see page 204)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 205)
:CHANnel<n>:SCALe?
(see page 205)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:UNITs
<units> (see
page 206)
:CHANnel<n>:UNITs?
(see page 206)
<units> ::= {VOLT | AMPere}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 207)
:CHANnel<n>:VERNier?
(see page 207)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
Table 6 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 7 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:CLEar (see
page 210)
n/a n/a
:DISPlay:DATA
[<format>][,][<area>]
[,][<palette>]<displa
y data> (see
page 211)
:DISPlay:DATA?
[<format>][,][<area>]
[,][<palette>] (see
page 211)
<format> ::= {TIFF} (command)
<area> ::= {GRATicule} (command)
<palette> ::= {MONochrome}
(command)
<format> ::= {TIFF | BMP |
BMP8bit | PNG} (query)
<area> ::= {GRATicule | SCReen}
(query)
<palette> ::= {MONochrome |
GRAYscale | COLor} (query)
<display data> ::= data in IEEE
488.2 # format
